Product Summary
The MAX3232EWE is a True RS-232 Transceiver. It has a proprietary low-dropout transmitter output stage enabling true RS-232 performance from a 3.0V to 5.5V supply with a dual charge pump.
Parametrics
Absolute maximum ratings: (1)VCC:-0.3V to +6V; (2)V+:-0.3V to +7V; (3)V-:+0.3V to -7V; (4)V+ + V- :+13V; (5)Input Voltages:T_IN, SHDN, EN:-0.3V to +6V,MBAUD:-0.3V to (VCC +0.3V),R_IN:±25V; (6)Output Voltages:T_OUT:±13.2V,R_OUT:-0.3V to (VCC + 0.3V); (7)Short-Circuit Duration:T_OUT:Continuous; (8)Operating Temperature Ranges:-40℃ to +85℃; (9)Storage Temperature Range:-65℃ to +150℃; (10)Lead Temperature (soldering, 10sec):+300℃.
Features
Features: (1)Low Supply Current:300μA; (2)Guaranteed Data Rate:120kbps; (3)Pin compatible with industry-standard MAX232; (4)Guaranteed Slew Rate:6V/μs.
Diagrams
