Product Summary

The AD7572AKN is a complete 12-bit ADC that offers high speed performance combined with low, CMOS power levels.

Parametrics

Absolute maximum ratings: (1)VDD to DGND: -0.3 to +7 V; (2)VSS to DGND: +0.3 to -17 V; (3)AGND to DGND: -0.3 to VDD+0.3V; (4)AIN to DGND: -15 to +15 V; (5)digital input voltage to DGND: -0.3, VDD+0.3V; (6)digital output voltage to DGND: -0.3, VDD+0.3V; (7)operating temperature range: 0 to 70℃; (8)storage temperature: -65 to +150℃.

Features

Features: (1)improved AD7572: faster conversion time: 3μs, 5V and -12V or -15V power supply operation, better offset and gain error specifications; (2)extended plastic temperature range (-40℃ to +85℃); (3)low powe: 100 mW; (4)SOIC DIP package.

Diagrams
